1. Maximum heat transfer; 2. Curving passage creates high turbulence...
Features 1. Compressor: adopt international brand semi-closed ...
• Unique floating coil design avoids leakage caused by thermal...
1.Cooling capacity: 7.5KW-93.6KW 2.Refrigerant: R22（R407C/R410A）...
1. Compressor: Vortex type compressor, adopt international brand fully enclosed vortex type maintenance-free compressor;
2. Heat exchanger: 5HP or bigger model, use high-efficiency shell and tube evaporator and condenser ;
3. Control system: Our own cotrol system, simple operation, accurate control;
4. Man-machine interface: The use of a well-known brand controller and control interface, digital display, one key operation;
5. Water tank: Adopt the overall design and manufacture, the built-in standard high-efficiency centrifugal pipeline pump, 304 stainless steel storage tank;
6. Different series of scroll compressors are used to meet different needs. Refrigeration water temperature can be adjusted from 15 degrees to -35 degrees, while sophisticated technology ensures working stability under extreme conditions;
7. The choice of environmental protection type: R407C, R134a.
Water chiller parameters (output temp 7℃)
1.Freezing water inlet temperature 12 ℃, freezing water outlet temperature 7 ℃; cooling water inlet temperature of 30 ℃, cooling water outlet temperature of 35 ℃;
2.Temperature conditions: Freezing water outlet temperature range 5 ℃ -15 ℃, cooling water inlet temperature range 19 ℃ -33 ℃;
3.Safe operating range: Freezing water inlet temperature 9℃-20℃;
4. The using compressor is a closed turbine imported from Europe and theUnited States, superior performance, strong ability of anti-effusion;
5. Nominal operating conditions in the evaporator and condenser water side fouling factor of 0.018m²℃/kw, condenser water side fouling factor of 0.044 m²℃/kw;
6. Water side of the evaporator and condenser, designed to withstand a pressure of 1.0MPa;
7. The actual head of Host is that the pump head minus head losses within the host;
8. In addition to the specifications and requirements. We can provide non-standard products according to customer requirements.
