Mixed Flow Inline Fan

Brief Description
Application

Mixed flow duct fan can be used for exhaust and supply ventilation systems that require high pressure, powerful airflow with low noise,. With a range of sizes including 100, 125, 150 and 200mm. Mixed flow duct fan can be used with rigid and flexible air duct. This kind of fan is the ideal solution for air exhaust systems for rooms with high humidity such as bathrooms and kitchens. As well as ventilation for apartments, Houses, shops, cafes, restaurants, cinemas etc.

Designation

The motor is attached to the body of the fan by two quick release clips which enables the motort o rotate to provide connection for confined spaces and removal for maintenance without removing the whole fan or duct. All models have an option of standard which has a two speed motor or overrun timer option variable range of 1 to 30 minutes.

Motor
The single phase ball bearing motor has two speeds and is equipped with standard thermal overload protection (STOP) with automatic restart. Motor protection rating IP44 and are fully speed controllable. Complies with part F building regulations and designed for ambient temperatures -20~60°C. Supply voltage 110V~380V, 50/60HZz.

Mounting
The fan can be mounted in line or at either and of the duct run and at any angle. Horizontally or vertically. All fans can be mounted in parallel to increase the volume of air or in series to increase the pressure. The casing is fitted with a mounting plate. The mounting box can be rotated to be installed in any positon for easy installation and connection.

Product Description

Model

Description

Stalls

Specification

Packing

Voltage

(V/Hz)

Current

(Amps)

Power

(W)

Speed

(RPM)

Air Flow

(M3/H)

Pressure

(Pa)

Noise

(db 3m)

Weight

(kg)

inner carton

size(mm)

outer carton

size(mm)

HF-100P

(4")

1 bearing: Ball bearing

2 windings :Copper

3 motor: Series motor

4 shellPP

5 impeller:ABS

H

230v/50hz

0.12

26

2200

198

156

31

2

320*220*245

500*340*680

L

230v/50hz

0.11

23

1850

165

131

26

1*6

HF-125P

(5")

1 bearing: Ball bearing

2 windings :Copper

3 motor: Series motor

4 shellPP

5 impeller:ABS

H

230v/50hz

0.14

33

2250

284

159

31

1.8

275*220*245

685*285*485

L

230v/50hz

0.13

28

1950

248

106

26

1*6

HF-150P(6")

1 bearing: Ball bearing

2 windings :Copper

3 motor: Series motor

4 shellPP

5 impeller:ABS

H

230v/50hz

0.24

54

2500

530

300

33

2.7

340*245*260

495*340*490

L

230v/50hz

0.21

48

1850

410

240

29

1*4

HF-200P(8")

1 bearing: Ball bearing

2 windings :Copper

3 motor: Series motor

4 shellPP

5 impeller:ABS

H

230v/50hz

0.53

140

2400

840

352

39

4.9

316*255*257

500*340*680

L

230v/50hz

0.52

132

1950

585

251

33

1*4
